*Note: production of this amp ended in 2015.

KT-45

“Here’s that amp that’ll finally help you get those Classic Rock sounds out of your head and into your hands” – Dr. Z

Specifications

Power Output45 Watts
Output Tubes2 – EL34
Preamp Tubes1 – EF86 (NOS), 1 – 12AX7
RectifierSolid State / 5AR4
ControlsVolume, Bass, Treble
ConfigurationsHead
ColorsBlack, Blonde, Red
Dimensions & WeightHead: 17 3/4″ W, 10″ H, 9 3/4″ D; 35 lbs.
Owners ManualDownload

General Information

The KT-45 is yet another completely original design from the Doctor. The basis of this amp’s design is its EF-86 (preamp tube) front-end and Tone Stack also used on the Z28 and Route 66 models. The incredible timbre of the EF-86, along with gain that’s 50% higher than the hottest 12AX7, virtually inhales the tone straight through your guitar cord. The KT-45’s tone stack allows control of the gain in three separate parameters- gain and amount of distortion in the treble registers, clear to swelling bass in the lower registers, and overall volume and drive. This allows you to dial in a Thick Top End, with a clean punching bass, or a swelling bottom end with crystalline highs. This is all done with plenty of clean to satisfy a Country picker, enough crunch for Rock & Roll, and tough singing sustain for R&B (British R&B that is!).

Sonically the KT-45 captures the rich tones of the WHO’s “Live at Leeds” LP. It combines powerful driving distorted tones with a touch of defined articulation. VOX AC-30/4 meets HiWatt.

Magazine Reviews

Please check back for new review postings.

Disclaimer: while the information contained on this page is correct at the time of publication, due to our policy of constant improvement and development, Dr. Z Amplification reserves the right to alter specifications without prior notice.
